    1X16 Character LCD Display | FSTN+ with RGB Backlight-Arduino

    Ask Lasest Price
    Brand Name : HOTHMI
    Model Number : HTM1601C-35S-A5P
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 99999
    Delivery Time : 25 days
    • Product Details
    • Company Profile

    1X16 Character LCD Display | FSTN+ with RGB Backlight-Arduino

    HTM1601C-41W-A5P.jpg1X16 Character LCD Display | FSTN+ with RGB Backlight-Arduino


    ▶ Product type: Standard COB character LCD module

    ▶ Display content: 16x1 characters

    ▶ Overall dimensions (mm): 122.0x33.0x8.0

    ▶ View window size (mm): 99.0x13.0

    ▶ Display size (mm): 94.73x9.56

    ▶ Point spacing mm: 1.17x1.04

    ▶ Product application: industrial control

    ▶ Viewing angle: 6H

    ▶ Backlight: red/green/blue light

    ▶ Number of PINs: 16PIN

    ▶ Interface: MCU

    ▶ Special instructions: Anti-static ESD 8KV

    ▶ Working temperature: -20~70℃

    ▶ Power supply voltage: 5.0v

    ▶ Driver chip: ST7066U


    HTM1601C-35S-A5P | 1x16 Characters | Serial SPI, I2C, or RS232 Interface | Transflective LCD | RGB Backlight | FSTN (+) Positive Display

    Hot Display character Liquid Crystal Display shows characters with dark pixels on a light background. The RGB display includes three backlight colors built into each display, which enables you to choose from a red, green or a blue backlight color. You can also mix the intensities of those colors to create new custom colors. This transflective LCD Display is visible with ambient light or a backlight while offering a wide operating temperature range from -20 to 70 degrees Celsius. This HTM1601C-35S-A5P serial interface display is fully compatible with Arduino, making it a convenient choice for DIY electronics projects and educational purposes. With an optimal view of 6:00, it operates at 5.0V supply voltage and is RoHS compliant.
