    8.0 Inch 800x1280 IPS LCD Display MIPI NV3051F1 Technology TFT Module

    Ask Lasest Price
    Brand Name : HOTHMI
    Model Number : TFT-H080B7HDINV6N30
    Payment Terms : L/C, D/A, T/T, D/P, Western Union, MoneyGram
    Supply Ability : 99999
    Delivery Time : 25 days
    • Product Details
    • Company Profile

    8.0 Inch 800x1280 IPS LCD Display MIPI NV3051F1 Technology TFT Module

    8.0 Inch 800x1280 IPS LCD Display MIPI NV3051F1 Technology TFT Module


    8.0 Inch 800x1280 IPS LCD Display MIPI NV3051F1 TFT Module Sunlight Readable

    TFT-H080B7HDINV6N30 | 8.0" IPS LCD | 800x1280 Pixels | Sunlight Readable

    Introducing the TFT-H080B7HDINV6N30 a 8.0 inch IPS LCD display that boasts a high resolution of 800x1280 pixels, delivering stunning visuals with vivid colors and crisp details. With its advanced technology, this display is also designed to be sunlight readable, ensuring optimal visibility even in bright outdoor environments.

    Whether you're using it for gaming, streaming videos, or browsing the web, this TFT module is the perfect solution for your display needs. Its MIPI NV3051F1 technology ensures fast and efficient data transmission, while its IPS panel provides wide viewing angles and excellent color accuracy.

    Upgrade your device with the TFT-H080B7HDINV6N30 and experience a new level of visual clarity and performance.


    General information


    ItemSpecificationUnit
    Outline Dimension114.70x184.20x2.65mmmm
    Display area107.64x172.224mmmm
    Number of Pixel800(H) x 1280(V)pixels
    Pixel pitch-mm
    Pixel arrangementRGB Vertical Stripe
    Display modeNormally Black
    NTSC70(Typ.)%
    Surface treatmentAntiglare, Hard-Coating (3H)
    Weight-g
    Back-lightSingle LED (Side-Light type)

    Power

    Consumption

    Logic System (White Pattern)NV3051W
    B/L System-W

    TFT Pin Description


    Pin NO.

    Symbol

    Description

    1GND

    Power supply ground

    2D2P

    LVDS Positive data signal (+)

    3D2N

    LVDS Negative data signal (-)

    4GND

    Power supply ground

    5D1P

    MIPI Positive data signal (+)

    6D1N

    MIPI Negative data signal (-)

    7GND

    Power supply ground

    8DCKP

    MIPI Positive clock signal (+)

    9DCKN

    MIPI Negative clock signal (-)

    10GND

    Power supply ground

    11D0P

    MIPI Positive data signal (+)

    12D0N

    MIPI Negative data signal (-)

    13GND

    Power supply ground

    14D3P

    LVDS Positive data signal (+)

    15D3N

    LVDS Negative data signal (-)

    16 ~ 17GND

    Power supply ground

    18RESX

    Reset pin

    19IOVCC

    IO Supply Voltage

    20NC

    Not connected

    21 ~ 22VCI

    Power supply

    23NC

    Not connected

    24 ~ 26LEDK

    LED cathode

    27NC

    Not connected

    28 ~ 30LEDA

    LED anode

    All Products


    Reliability TestingCustomers can expect all production parts to meet or exceed operational requirements over temperature, humidity, and vibration.
    Glass CleanlinessCustomers can expect glass to be protected by liners and presented mindful of cleanliness standards. This means glass will be clean of contaminants, fingerprints, and other foreign material.
    Bezel AppearanceBezels will be uniformly painted free of foreign materials and distracting cosmetic blemishes. Our standards maintain a clean scratch-free surface.
    PCB AppearancePCB’s are delivered with long-term reliability in mind. Finishes are free of bubbles, foreign contaminants, and meet all UL fire requirements. PCB materials will always be delivered within industry norms. PCB edges will be cleanly cut and void of burrs.
    SolderingSoldering of all leaded and SMT components is consistent in providing the mechanical security and electrical connectivity.
    ConsistencyOur manufacturing and inspection processes ensure product consistency from lot to lot. This means orders processed over the years will continually meet your expectations. We do this by exacting manufacturing specifications, with attention to detail in our processes, and by comparing to the golden units.
    Product IntegrityQuality in product manufacturing ensures integrity in construction. Customers can expect tight assembly without worry of loose parts or missing material. Our products will meet all environmental expectations including temp, humidity, & vibration conditions.
    Glass ColorWhile normal variations of glass color may occur (due to manufacturing tolerances), Newhaven Display maintains color compliance per internal approved color charts. These charts are maintained to ensure any minor glass deviations are identified and corrected as needed.
    ESD Protection & SafetyAll devices are designed and handled in consideration of ESD protection. This includes ESD-SAFE packaging within anti-static bags, wraps, and trays. Customers are reminded to always follow ESD safety to best protect the devices.

    Search keyword: tft 8.0, tft 8.0", 8.0 tft lcd, 8.0" tft lcd, 8.0 inch tft lcd, tft lcd 8.0, 8.0 tft display, 8.0" tft display,8.0inch tft display, tft display 8.0, tft display 8.0"

    8.0 Inch 800x1280 IPS LCD Display MIPI NV3051F1 Technology TFT Module8.0 Inch 800x1280 IPS LCD Display MIPI NV3051F1 Technology TFT Module8.0 Inch 800x1280 IPS LCD Display MIPI NV3051F1 Technology TFT Module8.0 Inch 800x1280 IPS LCD Display MIPI NV3051F1 Technology TFT Module8.0 Inch 800x1280 IPS LCD Display MIPI NV3051F1 Technology TFT Module8.0 Inch 800x1280 IPS LCD Display MIPI NV3051F1 Technology TFT Module8.0 Inch 800x1280 IPS LCD Display MIPI NV3051F1 Technology TFT Module8.0 Inch 800x1280 IPS LCD Display MIPI NV3051F1 Technology TFT Module8.0 Inch 800x1280 IPS LCD Display MIPI NV3051F1 Technology TFT Module

    TFT Custom Solutions

    8.0 Inch 800x1280 IPS LCD Display MIPI NV3051F1 Technology TFT Module

    Cable Customization

    Adjust the length, position, and pinout of your cables or add additional connectors. Get a cable solution that’s precisely designed to make your connections streamlined and secure.


    8.0 Inch 800x1280 IPS LCD Display MIPI NV3051F1 Technology TFT Module

    Touchscreen Add-on

    Enhance your user experience with capacitive or resistive touch screen technology. We’ll adjust the glass thickness or shape of the touch panel so it’s a perfect fit for your design.


    8.0 Inch 800x1280 IPS LCD Display MIPI NV3051F1 Technology TFT Module

    Interface Customization

    Choose from a wide selection of interface options or talk to our experts to select the best one for your project. We can incorporate HI, USB, SPI, VGA and more into your display to achieve your design goals.


    8.0 Inch 800x1280 IPS LCD Display MIPI NV3051F1 Technology TFT Module

    Cover Glass

    Equip your display with a custom cut cover glass to improve durability. Choose from a variety of cover glass thicknesses and get optical bonding to protect against moisture and debris.
