5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control

    Buy cheap 5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control from wholesalers

    Buy cheap 5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control from wholesalers
    • Buy cheap 5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control from wholesalers
    • Buy cheap 5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control from wholesalers
    • Buy cheap 5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control from wholesalers
    • Buy cheap 5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control from wholesalers

    5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control

    Ask Lasest Price
    Brand Name : HOTHMI
    Model Number : LCM-TFT056T1VGM2N30F
    Payment Terms : L/C, D/A, T/T, D/P, Western Union, MoneyGram
    Supply Ability : 99999
    Delivery Time : 25 days
    • Product Details
    • Company Profile

    5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control

    5.6 INCH MIPI TFT LCD PANEL 640X480 IPS LCD MONITORS FOR INDUSTRIAL CONTROL


    LCM-TFT056T1VGM2N30F | 5.6" IPS LCD Display | TFT LCD Display Manufacturer | 640x480 resolution | -20℃~70℃ | FOR INDUSTRIAL CONTROL | Interface MIPI


    Introducing the LCM-TFT056T1VGM2N30F, a high-quality 5.6-inch IPS LCD display designed for industrial control applications. With a resolution of 640x480 pixels, this TFT LCD display offers crisp and clear visuals, making it ideal for applications that require precise and accurate image display.

    Built to withstand harsh industrial environments, this display has a wide operating temperature range of -20℃ to 70℃, ensuring reliable performance even in extreme conditions. Its IPS technology also allows for wide viewing angles, ensuring that images remain clear and visible from different angles.

    This display is equipped with a MIPI interface, making it easy to integrate into existing systems. As a leading TFT LCD display manufacturer, we have designed this display with the highest quality standards to ensure its durability and longevity.

    Whether you need to monitor industrial processes or display critical information in real-time, the LCM-TFT056T1VGM2N30F is the ideal solution for your industrial control needs. Trust in our expertise and quality manufacturing to deliver exceptional performance and reliability in even the toughest industrial environments.


    General Feature


    Item

    Standard Value

    Unit

    Display Size

    5.6

    Inch

    Number of Pixels

    640(H)*3(RGB)* 480(V)

    dots

    Active Area

    126.5(W) ×100.0(H) ×9.5

    mm

    Outline Dimension

    115.7x87.47

    mm

    Viewing Direction

    FULL O'clock

    -

    Interface

    MIPI

    -

    Driver IC

    --

    Driver Condition

    VCI=5.0V(Typ)

    V

    Backlight

    -

    -

    Touch Panel

    WHITOUT TOUCH

    CTP Driver IC

    --

    Driver Condition

    VDD=5.0

    V

    TFT Operation AT

    -20 ~ +70

    TFT Storage AT

    -30 ~ +85


    TFT Pin Description


    Pin No.NameFunction
    1-3VDDPower supply +5V.
    4GNDPower ground 0V.
    5-6NC--
    7GNDPower ground 0V.
    8NC--
    9GNDPower ground 0V.
    10BL_PWMPWM for LCD Backlight Dimming .
    11GNDPower ground 0V.
    12BL_ENBacklight Enable.
    13/RESActive low reset to the LCM.
    14NC--
    15GNDPower ground 0V.
    16-17NC--
    18GNDPower ground 0V.
    19-20NC--
    21GNDPower ground 0V.
    22DATAN1Negative differential data1 for DSI.
    23DATAP1Positive differential data1 for DSI .
    24GNDPower ground 0V.
    25DATAN0Negative differential data0 for DSI.
    26DATAP0Positive differential data0 for DSI.
    27GNDPower ground 0V.
    28CLOCKNNegative differential clock for DSI.
    29CLOCKPPositive differential clock for DSI.
    30GNDPower ground 0V.

    All Products


    Reliability TestingCustomers can expect all production parts to meet or exceed operational requirements over temperature, humidity, and vibration.
    Glass CleanlinessCustomers can expect glass to be protected by liners and presented mindful of cleanliness standards. This means glass will be clean of contaminants, fingerprints, and other foreign material.
    Bezel AppearanceBezels will be uniformly painted free of foreign materials and distracting cosmetic blemishes. Our standards maintain a clean scratch-free surface.
    PCB AppearancePCB’s are delivered with long-term reliability in mind. Finishes are free of bubbles, foreign contaminants, and meet all UL fire requirements. PCB materials will always be delivered within industry norms. PCB edges will be cleanly cut and void of burrs.
    SolderingSoldering of all leaded and SMT components is consistent in providing the mechanical security and electrical connectivity.
    ConsistencyOur manufacturing and inspection processes ensure product consistency from lot to lot. This means orders processed over the years will continually meet your expectations. We do this by exacting manufacturing specifications, with attention to detail in our processes, and by comparing to the golden units.
    Product IntegrityQuality in product manufacturing ensures integrity in construction. Customers can expect tight assembly without worry of loose parts or missing material. Our products will meet all environmental expectations including temp, humidity, & vibration conditions.
    Glass ColorWhile normal variations of glass color may occur (due to manufacturing tolerances), Newhaven Display maintains color compliance per internal approved color charts. These charts are maintained to ensure any minor glass deviations are identified and corrected as needed.
    ESD Protection & SafetyAll devices are designed and handled in consideration of ESD protection. This includes ESD-SAFE packaging within anti-static bags, wraps, and trays. Customers are reminded to always follow ESD safety to best protect the devices.

    Search keyword: tft 5.6, tft 5.6", 5.6 tft lcd, 5.6" tft lcd, 5.6 inch tft lcd, tft lcd 5.6, 5.6 tft display, 5.6" tft display,5.6 inch tft display, tft display 5.6, tft display 5.6"

    TFT-H035B16 V0-1_03.jpg

    5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control


    TFT Custom Solutions

    5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control

    Cable Customization

    Adjust the length, position, and pinout of your cables or add additional connectors. Get a cable solution that’s precisely designed to make your connections streamlined and secure.


    5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control

    Touchscreen Add-on

    Enhance your user experience with capacitive or resistive touch screen technology. We’ll adjust the glass thickness or shape of the touch panel so it’s a perfect fit for your design.


    5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control

    Interface Customization

    Choose from a wide selection of interface options or talk to our experts to select the best one for your project. We can incorporate HI, USB, SPI, VGA and more into your display to achieve your design goals.


    5.6" Inch MIPI TFT LCD Panel 640x480 IPS Lcd Monitors For Industrial Control

    Cover Glass

    Equip your display with a custom cut cover glass to improve durability. Choose from a variety of cover glass thicknesses and get optical bonding to protect against moisture and debris.
