    128X64 SPI Graphic LCD Module ST7565R With White Side Backlight HTM12864-7

    Ask Lasest Price
    Brand Name : HOTHMI
    Model Number : HTM12864-7
    Payment Terms : L/C, D/A, T/T, D/P, Western Union, MoneyGram
    Supply Ability : 99999
    Delivery Time : 25 days
    • Product Details
    • Company Profile

    128X64 SPI Graphic LCD Module ST7565R With White Side Backlight HTM12864-7

    128X64 SPI Graphic LCD Module ST7565R | FSTN Display With White Side Backlight/HTM12864-7

    HTM12864-7 | Monochrome Graphic Module | 128x64 Pixels | Transflective LCD | Side White Backlight | STN (+) Positive Display


    HOTLCD 128x64 graphic Liquid Crystal Display module shows dark pixels on a white background. This transflective LCD Display is visible with ambient light or a backlight while offering a wide operating temperature range from -20 to 70 degrees Celsius. This HTM12864-7 display has an optimal view of 6:00, operates at 3.3V supply voltage and is RoHS compliant.


    Product parameters


    ITEMSTANDARD VALUEUNIT
    Number of dots128x64dots
    Module dimension94.98x55.0 x7.8mmmm
    View display area65.4x37.8mm
    Dot size0.45x0.49mm
    Dot pitch0.475x0.515mm
    Operating temp-20~70
    Storage temp-30~80
    Driving Method1/ 128 DUTY,1/ 12 BIAS,VOP= 3.3V
    Viewing direction6H
    Display mode
    STN/YG
    Display typeTRANSMISSIVE / NEGATIVE
    Driver IC
    ST7565R
    Backlight

    WHITE

    Product applicationindustrial control, instrumentation

    Terminal Function


    Pin No.Pin NameFunction
    1/CSThis is the chip select signal.

    2


    RES

    When /RES is set to “L”, the register settings are initialized (cleared). The reset operation is performed by the /RES signal level


    3


    D/C

    This is con nect to the least significant bit of the normal MPU address bus, and it determines whether the data bits are data or command.

    4SCLThe serial clock input (SCL).
    5SISerial data input (SI)
    6VDDPower supply voltage (Positive)
    7VSSNegative power supply,0V
    8K(LED-)Negative power supply(Backlight)
    9A(LED+)Backlight Power supply voltage (Positive)

    Absolute Maximum Ratings


    ItemsSymbolMIN.MAX.UnitCondition
    Supply VoltageVDD-0.3+3.6VVSS = 0V
    Input VoltageVIN-0.3VDD+0.3VVSS = 0V
    Operating TemperatureTOP-10+60No Condensation
    Storage TemperatureTst-20+70No Condensation

    Electrical Characteristics

    ItemsSymbolMIN.TYP.MAX.UnitCondition
    Operating VoltageVDD3.03.33.6VVDD
    Input High VoltageVIH0.8 x VDD-VDDV

    /CS1,/RES,A0,/WR,

    /RD,D0~D7,C86

    Input Low VoltageVILVSS-0.2 x VDDV
    Output High VoltageVOH0.8 x VDD-VDDVD0~D7
    Output Low VoltageVOLVSS-0.2 x VDDVD0~D7
    Input Leakage CurrentILI-1.0-1.0μAVDD
    Output Leakage CurrentILo-3.0-3.0μAVDD

    ItemsSymbolMIN.TYP.MAX.UnitCondition
    Forword VoltageVf BLA-3.1-VVDD
    Forword CurrentIf BLA-1015mAVDD

    All Products


    Bezel AppearanceBezels will be uniformly painted free of foreign materials and distracting cosmetic blemishes. Our standards maintain a clean scratch-free surface.
    PCB AppearancePCB’s are delivered with long-term reliability in mind. Finishes are free of bubbles, foreign contaminants, and meet all UL fire requirements. PCB materials will always be delivered within industry norms. PCB edges will be cleanly cut and void of burrs.
    SolderingSoldering of all leaded and SMT components is consistent in providing the mechanical security and electrical connectivity.
    ConsistencyOur manufacturing and inspection processes ensure product consistency from lot to lot. This means orders processed over the years will continually meet your expectations. We do this by exacting manufacturing specifications, with attention to detail in our processes, and by comparing to the golden units.

    Search Keyword: lcd 128x64, lcd 128 x 64, 128x64 lcd, 128 x 64 lcd

    128X64 SPI Graphic LCD Module ST7565R With White Side Backlight HTM12864-7128X64 SPI Graphic LCD Module ST7565R With White Side Backlight HTM12864-7

    LCD Custom Solutions

    Cable Customization

    Adjust the length, position, and pinout of your cables or add additional connectors. Get a cable solution that’s precisely designed to make your connections streamlined and secure.

    128X64 SPI Graphic LCD Module ST7565R With White Side Backlight HTM12864-7
    128X64 SPI Graphic LCD Module ST7565R With White Side Backlight HTM12864-7

    Connector Customization

    Easily modify any connectors on your display to meet your application’s requirements. Our engineers are able to perform soldering for pin headers, boxed headers, right angle headers, and any other connectors your display may require.


    128X64 SPI Graphic LCD Module ST7565R With White Side Backlight HTM12864-7

    Interface Customization

    Choose from a wide selection of interface options or talk to our experts to select the best one for your project. We can incorporate HI, USB, SPI, VGA and more into your display to achieve your design goals.


    128X64 SPI Graphic LCD Module ST7565R With White Side Backlight HTM12864-7

    PCB Modifications

    Choose from a wide selection of changes including shape, size, pinout, and component layout of your PCB to make it a perfect fit for your application.


    128X64 SPI Graphic LCD Module ST7565R With White Side Backlight HTM12864-7

    HTM12864-7-05G-N3S Manual.pdf
