    20x2 MCU Character LCD Module Practical With Green Backlight HTM2002A

    Ask Lasest Price
    Brand Name : HOTHMI
    Model Number : HTM2002A
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 99999
    Delivery Time : 25 days
    • Product Details
    • Company Profile

    20x2 MCU Character LCD Module Practical With Green Backlight HTM2002A

    20x2 Character LCD | Green Backlight/HTM2002A


    Quick detail


    Product Type - Standard COB Character Module
    Display content - 20X2 characters
    Dimensions (mm) - 116.0X37.0X14.6
    Viewport window size (mm) - 83.0X18.6
    Display size (mm) - 75.4X11.5
    Dot Spacing mm - 0.65X0.7
    Product Application - Industrial Control
    Viewing Angle - 6H
    Backlight Type or Brightness - Yellow Green
    Connection method PIN number - 16PIN
    Interface - MCU/8bit
    Working temperature - (-20~70℃)
    Supply Voltage - 5.0v


    Terminal Function


    Pin No.Pin NameFunction
    1VSSPower Supply, (0V)
    2VDDPositive Power Supply (5.0V)
    3V0LCD Contrast Reference Supply

    4


    RS

    Select Register

    0:Instruction register (for write) busy flag address Counter(for read)

    1:Data register (for write and read)


    5


    R/W

    Select read or write 0: Write

    1: Read

    6EStarts data read/write
    7DB0

    Data Bus Lines

    8DB1
    9DB2
    10DB3
    11DB4
    12DB5
    13DB6
    14DB7
    15BLABacklight Positive(5.0V)
    16BLKBacklight Negative(VSS)

    Display Address


    1234567891011121314151617181920
    Line 18 08 18 28 38 48 58 68 78 88 98A8B8C8D8E8F90919293
