128X64 Gray COG LCD Module Graphic 66.52x33.24mm ST7565P HTG12864-103

Product Categories

Hotdisplay Technology Co.Ltd

Contact Now

128X64 Gray COG LCD Module Graphic 66.52x33.24mm ST7565P HTG12864-103

Ask Lasest Price
Brand Name :	HOTHMI
Model Number :	HTG12864-103
Payment Terms :	L/C, D/A, T/T, D/P, Western Union, MoneyGram
Supply Ability :	99999
Delivery Time :	25 days

Add to Cart

Product Details
Company Profile

128X64 Gray COG LCD Module Graphic 66.52x33.24mm ST7565P HTG12864-103

128X64 Graphic COG LCD ST7565P | FSTN Gray Display With White Side Backlight/HTG12864-103

HTG12864-103 | Monochrome Graphic COG | 128x64 Pixels | Transflective LCD | Side White Backlight | FSTN (+) Positive Gray Display | IN Stocked

HOTLCD 128x64 graphic Chip-On-Glass (COG) Liquid Crystal Display shows blue pixels on a gray background. This transflective LCD Display is visible with ambient light or a backlight while offering a wide operating temperature range from -40 to 70 degrees Celsius. This HTG12864-103 display has an optimal view of 6:00, operates at 3.3V supply voltage and is RoHS compliant.

Product parameters

ITEM	STANDARD VALUE	UNIT
Number of dots	128x64	dots
Module dimension	80x54x10.2	mm
View display area	66.52x33.24	mm
Dot size	0.48x0.48	mm
Dot pitch	0.52x0.52	mm
Operating temp	-20~70/-40~70	℃
Storage temp	-30~80	℃
Driving Method	1/ 128 DUTY,1/ 12 BIAS,VOP= 3.3V
Viewing direction	6H
Display mode	FSTN
Display type	TRANSMISSIVE / NEGATIVE
Driver IC	ST7565P
Backlight	WHITE
Product application	industrial control, instrumentation

Electrical Characteristics

Item	Symbol	Condition	Min	Typ	Max	Unit
Supply Voltage For Logic	VDD-VSS	－	2.7	3.0	3.3	V
Supply Voltage For LCM	VOP	Ta=-20℃ Ta=25℃ Ta=70℃	－ 9.15 －	－ 9.45 －	－ 9.75 －	V V V
Input High Volt.	VIH	－	0.7 VDD	－	VDD	V
Input Low Volt.	VIL	－	Vss	－	0.3VDD	V
Output High Volt.	VOH	－	0.8 VDD	－	VDD	V
Output Low Volt.	VOL	－	Vss	－	0.2 VDD	V
Supply Current	IDD	VDD=3.0V	－	0.45	0.9	mA
