4.3 Inch IPS SPI+RGB Interface TFT LCD Module 480x800 Resolution/TFT-H043A7WVIST5N40

Product parameters

Display Size - 4.3 inch
Perspective - Full Perspective
Backlight brightness - 500cd/m2
Connection method PIN number: FPC-40PIN
Interface mode: RGB
Working temperature: -20~70℃
Supply voltage: 3.3V
Driver chip model: ST7701S

General Feature:

Pin Description

DESCRIPTION

TFT-H043A7WVIST5N40 is a 4.3 inch IPS TFT-LCD display module; made of resolution 480 x 800 pixels. H043A7 module supports SPI+RGB interface (2 lanes), it featured with IPS panel which is having the advantages of wider viewing angle of Left:80 / Right:80 / Up:80 / Down:80 degree (typical), contrast ratio 720 (typical value), brightness 550 nits (typical value), Anti-Glare surface panel.

This 4.3 inch MIPI LCD display is portrait mode; it integrated driver IC ST7701S on module, interface supply voltage range 2.8V to 3.3V. This TFT module can be operating at temperatures from -20℃ to +60℃; its storage temperatures range from -30℃ to +80℃.

TFT-H043A7WVIST5N40.pdf
