12.3 Inch 1920x720 Sunlight Readable IPS TFT LCD Support HI
CTP/TFT-123T61FHHDVUSDC
Product parameters
Dimensions - 313.8x132.2x13.3
Display Size - 12.28 inches
Effective size (mm) - 292.032x109.512
Backlight brightness - 850cd/m2
Special Instructions - Industrial Grade
Working temperature - (-20~70℃)
Supply voltage - 12~24V
Special instructions - with capacitive touch function
Product introduction
- 12.3 inch display with 1920×720 HD resolution.
- 750 cd/m² high brightness, 50000 hours long life backlight.
- Support OSD control buttons to help users adjust the LCD screen
to the best state for different application environments,OSD menu
can be - switched in Chinese and English.
- Support VGA and HI signal input (choose one when using, cannot
identify at the same time)
- Supports multi-point USB interface drive-free capacitive touch
screen
- Support panel embedded installation, only need 6 screws to fix
the PCB,
easy installation and maintenance
- Compatible with mainstream operating systems and embedded
operating systems such as
DOS/Windows98/2000/XP/win7/win8/win10/Embedded/Linux.
LCD parameters
| Item | Standard Value | Unit |
| Display Size | 12.3 | Inch |
| Number of Pixels | 1920(H)*3(RGB)* 720(V) | dots |
| Active Area | 292.032(H)* 109.512(V) | mm |
| Outline Dimension | 328.128(H) * 142.128(V) * 30.10(D) <With CTP> | mm |
| Contrast Ratio | Type 1400:1 | - |
| Response Time | Type 25(Tr + Tf) | msec |
| Viewing Direction | Full View(U85/D85/L85/R85) | - |
| Maximum color | 16.7 M | Color |
| USB Touch Panel | Without TP With USB CTP | - |
| Operation Temperature | -20 ～ 70 | ℃ |
| Storage Temperature | -30 ～ 80 | ℃ |
HI Type A Connector Description
| Pin NO. | Symbol |
| 1 | TMDS D2+ |
| 2 | TMDS D2 Shield |
| 3 | TMDS D2- |
| 4 | TMDS D1+ |
| 5 | TMDS D1 Shield |
| 6 | TMDS D1- |
| 7 | TMDS D0+ |
| 8 | TMDS D0 Shield |
| 9 | TMDS D0- |
| 10 | TMDS CK+ |
| 11 | TMDS CK Shield |
| 12 | TMDS CK- |
| 13 | NC |
| 14 | NC |
| 15 | DDC CLK |
| 16 | DDC DATA |
| 17 | GND |
| 18 | +5V Power |
| 19 | HPD |
VGA Connector Description
| Pin NO. | Symbol |
| 1 | RED |
| 2 | GREEN |
| 3 | BLUE |
| 4 | NC |
| 5 | GND |
| 6 | GND |
| 7 | GND |
| 8 | GND |
| 9 | +5V Power |
| 10 | GND |
| 11 | NC |
| 12 | DDC DATA |
| 13 | HSYNC |
| 14 | VSYNC |
| 15 | DDC CLK |
product description
123T61FHHDVUSDC is a 12.3-inch 480x128 long strip TFT-LCD display
module with control board. The module has a built-in HI/DVI
decoding IC; it communicates through the DVI signal interface and
supports Raspberry Pi series. Its brightness is 750 nits; the
contrast ratio is 500:1, the viewing angle is omnidirectional, and
the surface uses anti-glare. It can work at a temperature of
-20°C~+70°C; its storage temperature range is -30°C~+80°C.
This widescreen bar 12.3 inch 123T61FHHDVUSDC TFT-LCD provides high
quality and colorful images; it is especially suitable for server
systems, audio systems, automotive/aviation/marine equipment,
security equipment, industrial equipment, outdoor intercom systems
and control panels, medical equipment, etc.
