8.0 inch TFT LCD display module/800x600 dot matrix TTL color screen/FPC plug STM32

Key Features:

▶ Model: TFT-H080A1SVTHX3N50

▶ Type: TFT standard display

▶ Display pixels: 800x1280 px

▶ Dimensions (mm): 182.9X141.0X7.0

▶ Display inches: 8.0"

▶ AA size (mm): 162.0X121.5

▶ Application: industrial control systems, portable electronic devices

▶ Viewing angle: 12 O'CLOCK (U70/D75/L75/R75)

▶ Backlight/brightness: 300cd/m2

▶ Pin: FPC-50 pin

▶ Interface mode: TTL 18/24 Bit

▶ Special instructions: Anti-static ESD 8KV

▶ Operating temperature: -20~70℃

▶ Supply voltage: 3.3V

▶ Driver chip: HX8264+HX8696

8.0 inch TFT LCD resistive touch display module/800x1280 dot matrix resistive touch color screen/FPC plug-in

8.0 inch TFT LCD resistive touch display module 800x1280 dot matrix resistive touch color screen FPC plug-in TFT-H080A1SVTHX3R50 is an 8.0 inch IPS TFT display with a resolution of 800x1280 pixels. The best viewing angle is 12 O'CLOCK (U70/D75/L75/R75). This model uses FPC connection, and FPC requires a connector. Just connect with our optional solder FPC connector, which is easy to insert or remove.

This display also has a brightness of up to 300cd/m2.

For users using 8051 microcontrollers, we have also prepared a detailed tutorial that includes interface information, demo code, and development kits. You can contact us to request and learn

Typical Applications:

Industrial Instruments: Used in devices requiring high-resolution displays.

Smart Devices: Ideal for wearable devices, handheld gadgets, and IoT devices.

Embedded Systems: Compatible with a wide range of microcontrollers and development boards.

Advantages:

High Picture Quality: Sharp and clear display with a resolution of 320x320.

Wide Viewing Angle: Ensures good visibility from different angles.

Flexible Interface Options: Supports both parallel and serial interfaces, making it versatile for different applications.

Environmental Compliance: Meets RoHS standards, ensuring it is environmentally friendly.

Pin Configuration and Interface:

The module supports multiple interface options, allowing it to be easily integrated into various systems. The specific pin configuration will depend on the interface mode selected (parallel or serial).

Development Support:

The module is compatible with a wide range of MCU platforms, making it easy to integrate into existing projects. It is particularly well-suited for use with popular development boards like Arduino, Raspberry Pi, and STM32.

Conclusion:

The TFT-H027A01HQINV4N40 is a versatile and high-quality TFT LCD module suitable for a wide range of applications. Its support for multiple interfaces and compatibility with various MCU platforms make it an excellent choice for developers looking for a reliable display solution.
