The 3.0inch 128x64 Graphic LCD Display Module with dark blue pixels
on a gray background is a highly adaptable and durable display
solution designed for optimal visibility across various lighting
conditions and environments. Below is a detailed breakdown of its
features, specifications, and applications:
Key Features:
1. HighContrast Display:
Displays dark blue pixels on a gray background, ensuring excellent
contrast and readability.
The translucent LCD screen is engineered for clear visuals in both
bright and dark environments.
2. Adaptive Visibility:
Bright Sunlight: Utilizes a reflective layer to bounce ambient
light back to the viewer, making the screen easy to read even in
direct sunlight.
Dark Environments: Features a strong builtin backlight that
delivers high contrast and crisp graphics.
3. Advanced Display Technology:
Ensures the screen remains easy to read regardless of lighting
conditions, making it suitable for indoor and outdoor use.
4. Compatibility:
Fully compatible with Arduino, making it ideal for hobbyists,
developers, and engineers.
Can be seamlessly integrated with other electronic systems for
diverse applications.
5. Durability:
Built to withstand harsh operating conditions.
Operates reliably in a wide temperature range of 20°C to 70°C.
6. Optimal Viewing Angle:
Designed with a 6:00 viewing angle, ensuring clear visibility from
a standard perspective.
7. Low Power Consumption:
Operates on a 3.3V supply voltage, making it energyefficient and
suitable for lowpower applications.
8. RoHS Compliance:
Meets RoHS standards, ensuring it is free from hazardous substances
and environmentally friendly.
Applications:
Outdoor Equipment: Ideal for devices exposed to sunlight, such as
agricultural tools, navigation systems, or outdoor signage.
Industrial Control Systems: Suitable for use in environments with
extreme temperatures or demanding conditions.
Consumer Electronics: Perfect for devices requiring clear and
bright displays.
IoT and Smart Devices: Easily integrated into Arduinobased projects
or other microcontroller systems.
Automotive Displays: Can be used in vehicles due to its wide
temperature tolerance and sunlight readability.
Medical Equipment: Reliable performance in critical applications.
| Item | Specification | Unit |
| Model | HTM-12864-85-11W-A3P | |
| Column × Row | 128 columns × 64rows | dots |
| Module Size | 71.0 x 62.0 x 7.8 (MAX) | mm |
| Visual (VA) Area | 65.5 x 38.8 | mm |
| Active (AA) Area | 60.77 x 32.93 | mm |
| Pixel Pitch | 0.515 x 0.475 | mm |
| IC | ST7565R | |
| Power Supply Voltage | 3.3V | V |
| Backlight | White | |
| Mode | STN(+) | |
| Drive Mode (Duty) | 1/64 duty cycle | |
| Type | Graphic LCD | |
| Features | Transflective |
